Galaxy G1 Plus

    Model: Galaxy G1 Plus

    Features

    G1


    Behind every significant epoch-making change in human society, always accompanied by the birth of an important technology.

    Computer and electronics make surveying and mapping industry achieve a span from the analog age to the digital age.

    And the development of Internet technology further opens the prelude of surveying and mapping information age.

    In the form of the ubiquitous, internet is penetrating and fusion in all corners of the surveying technology, and setting off an unprecedented reconstruction and

       transformation.

    In the dawn of a new era, south is walking in front of it to craft Galaxy 1plus which opening a '+' era of high-precision positioning applications.



    G1+

    Specification

    GNSS performance Channels 336, 555 (optional)
    GPS L1 C/A, L2E, L2C, L5
    GLONASS L1 C/A, L2 C/A, L3
    BDS B1, B2, B3
    GALILEO E1, E5A, E5B, E5AltBOC, E6
    SBAS L1 C/A, L5
    QZSS, WAAS, MSAS, EGNOS, GAGAN
    L-Band RTX Function
    Positioning output rate 1, 5, 10, 20 ~ 50Hz
    Initialization time <10s
    Initialization reliability >99.99%
    Positioning precision Static surveying Horizontal: 2.5mm+0.5ppm; Vertical: 5mm+0.5ppm
    Code differential positioning Horizontal: 0.25m+1ppm; Vertical: 0.50m+1ppm
    Real-time kinematic surveying Horizontal: 8mm+1ppm; Vertical: 15mm+1ppm
    RTX Horizontal: 4-10cm (5-30min); Vertical: 8-20cm (5-30min)
    SBAS positioning Typically<5m 3DRMS
    xFill
    IMU tilt compensation
    Single positioning --
    User interaction Operaing system Linux
    Buttons 2 buttons operation
    LCD --
    Indicators 5 indicate lights
    Web UI Freely to configure and monitor the receiver by accessing to the web server via Wi-Fi and USB
    Voice guide iVoice intelligent voice technology provides status and voice guide, Supports Chinese, English, Korean, Russian, Portuguese, Spanish, Turkish and user define
    Secondary development Providing secondary development package
    Data cloud service --
    Hardware performance Dimension 135mm (Diameter) x 125mm (Height)
    Weight 1.29kg (with two batteries)
    Material Magnesium aluminum alloy shell
    Operating temperature -30°C ~ +65°C
    Storag temperature -40°C ~ +80°C
    Humidity 95% Non-condensing
    Waterproof/Dustproof IP67 standard, protected from long time immersion to depth of 1m, and fully protected against blowing dust
    Shock and vibration Withstand 2 meters drop onto the cement ground naturally
    Power Supply 9-25V DC, overvoltage protection
    Battery Rechargeable, removable Lithium-ion battery, 7.4V 3400mAh/per
    Battery solution Supports one or two batteries installed; supports power pole connection (optional); 4 standard batteries power package (optional)
    Battery life Single battery: >10h (static mode), >6h (internal UHF base mode), >8h (rover mode)
    Communications I/O port 5-PIN LEMO external power port + RS232, 7-PIN external USB(OTG)+Web accessing, 1 radio antenna interface, SIM card slot
    Wireless modem Built-in radio, 1W/2W/3W switchable, typically work range can be 8KM
    Frequency Range 410-470MHz
    Communication Protocol TrimTalk450s, SOUTH, SOUTH+, huace, ZHD, Satel
    Cellular Mobile Network TDD-LTE, FDD-LTE 4G network modem
    Double Module Bluetooth BLEBluetooth 4.0 standard, Bluetooth 2.1 + EDR standard
    NFC Communication Realizing close range (shorter than 10cm) automatic pair between receiver and controller
    External Devices Optional external GPRS/EDGE dual-mode communication module, switchable
    WIFI Standard 802.11 b/g standard
    WIFI Hotspot The WIFI hotspot allows any mobile terminal to connect and access to the internal webserver for the control and moditor receiver
    WIFI data link To work as the datalink that receiver is able to broadcast and receive differential data via WIFI
    Data storage/ Transmission Data Storage 8GB SSD internal storage, supports external USB storage and automatical cycle storage, changeable record interval, up to 50Hz raw data collection
    Data Transmission USB data transmission, supporting FTP/HTTP data download
    Data Format Static data format: STH, Rinex2.x and Rinex3.x etc
    Differential data format: CMR+, SCMRx, RTCM 2.1, RTCM 2.2, RTCM 2.3, RTCM 3.0, RTCM 3.1, RTCM 3.2
    GPS output data format: NMEA 0183, PJK plane coordinates, binary code, Trimble GSOF
    Network model support: VRS, FKP, MAC, supporting NTRIP protocol
    Inertial sensing system Tilt survey Built-in tilt compensator, correcting coordinates automatically according to the tilt direction and angle of the centering rod
    Electronic bubble Controller software display electronic bubble, checking leveling status of the centering rod real time
    Thermometer Built-in thermometer sensors, adopting intelligent temperature control tech nology, monitoring and adjusting the receiver temperature in real time

    Note: all information above is subject to change without any prior notice.
