X2

    ● New design appearance and very comfortableto hold ● HD large 5inch touch screen fulfilling the Android users needs ● Quad-Core 1.5GHz processor ● Multiple sensors and more extended functions ● Micro-USB port and OTG function

Model: X2

Download:

X2 Brochure

Features

Professional GIS Collector

The new generation hand-held GPS polar X series, Android 5.1 OS installed, applied Octa-Core 1.5GHz processor inside. Integrating multiple sensors which is very useful in the field work.


X2 handheld is a durable, compact GIS collector with an integrated high-yield GPS receiver, ideal for asset management and inspection applications. It is the latest addition to the X series family of GPS handhelds from South, providing an affordable platform to arm an entire mobile workforce with a reliable and accurate professional GPS handheld incorporating the Windows Embedded Handheld OS/Android OS. X2 adopts professional GPS module, 72 channels, GPS, BDS and BGLONASS(optional) tracking, ensure faster satellite tracking and more reliable positioning result. Compatible with GIS oriented workflows, X2 is the smart solution you can trust for standardizing inspections and asset management.


It may look like a smartphone, but X2 is all business. Rugged cover meets the need of filed work. It has a large screen so you can easily view data or photos even in direct sunlight.

You can be confident that your teams have a real, professional tool -- built to work in even the tough conditions.


Specification

System Operating system Android 5.1
CPU Octa-Core 1.5GHz
Memory 3GB RAM, 32GB ROM
Storage up to 128G extensible
GNSS performance Channels 72
GPS L1, BD1
GLONASS L1 (optional)
BDS B1
GALILEO -
SBAS -
QZSS -
Data output NEMA-0183
I/O protocol RTCM2.3 (1,3,9), RTCM31
Update rate 1Hz
Reacquisition <1s
Warm start -
Cold start <30s
Accuracy Single positioning 5m
SBAS positioning 2 ~ 5m
DGNSS 1 ~ 3m
RTK(baseline<30km) -
Multimedia Camera 8.0 megapixel AF, flashlight
Display 5.0 inch capacitive screen, 1280 × 720
Sensor Electronic compass, gravity sensor, built-in thermometer, atmospheric pressure altimeter, light sensor and distance sensor (optional)
Other function Integrated speakers and microphone
Extended function(optional) Scanning head, NFC, backtalk, Fingerprint identification
Communication network WCDMA 3G modem
Bluetooth BT4.0 downward compatible to BT2.1 + EDR
WIFI IEEE 802.11 b/g/n
USB Micro USB, support charging and OTG function
Electrical Battery 3.7V, 4200mAh Li-Ion, 2 batteries (standard)
Battery life Single battery > 10 hrs
Battery charging 2 stands charger, 4 hrs fast charging
Environment Waterproof/Dustproof IP67
Shockproof 1.5m
Humidity -
Operating temperature -
Storage temperature -40℃ ~ 80℃
Physical Dimension 156mm(L) × 85mm(W) × 29mm(H)
Weight 0.32kg (battery included)

Note: all information above is subject to change without any prior notice.
