SVP60

    Model: SVP60

    Download:

    Sound Velocity Profiler SVP60 brochure

    Features

    As a typical self-contained sound velocimeter, SVP60 features its time-of-flight measurement of acoustic ping. It may rapidly accomplish the underwater missions of sound velocity profiling within its measuring range.


    The onboard GNSS positioning module helps with each sounding measurement and the specific non-physical-structural magnetic switch is more durable and trustworthy. This instrument provides realtime sounding profile data for error corrections to all types of sounding equipment like echo sounder, sonar, underwater sonic, etc. which makes it a necessary tool for hydro and watercourse survey, ocean research and reconnaissance, and national defense applications.


    Plenty of job practices made it a field-proven product in terms of accuracy and reliability.


    A9oyuyi0_17gv8ji_nl0

    Specification

    TECHNICAL Velocity Range 1375-1900 m/s
    Velocity Resolution 0.001 m/s
    Velocity Accuracy ±0.02 m/s
    Depth Measuring Range 0-200 m
    Depth Measuring Resolution 0.01 m
    Depth Measuring Accuracy ±0.05 m
    ENVIRONMENTAL Working Temperature -5℃ ~ 40 ℃
    Temperature Sensing Resolution 0.001 ℃
    Temperature Sensing Accuracy 0.01 ℃
    PHYSICAL Housing Material aluminum hard anodized
    ELECTRICAL Communicating Interface Bluetooth transfer
    OTHERS GNSS Positioning GPS + Glonass + Beidou
    Switch Mode magnetic

    10
