Specification

System	Operating system	Android 8.1
	CPU	Octa-Core 2.0GHz
	Memory	4GB/ 6GB (optional) RAM, 64GB ROM
	Storage	Up to 128GB
GNSS performance	Channels	-
	GPS	L1
	GLONASS	L1 (optional)
	BDS	B1
	GALILEO	-
	SBAS	-
	QZSS	-
	Data output	-
	I/O protocol	-
	Update rate	-
	Reacquisition	-
	Warm start	-
	Cold start	-
Accuracy	Single positioning	5m
	SBAS positioning	2 ~ 5m
	DGNSS	1 ~ 3m
	RTK(baseline<30km)	-
Multimedia	Camera	5.0 MP AF front camera, 13.0 MP AF rear camera, LED flashlight
	Display	6.0 inch, PS HP screen, 2160×1080, HD+, 18:9
	Sensor	Compass, Geomagnetism, Acceleration, Photosensitive Distance, Air Pressure (Optional), Gyroscope (Optional)
	Other function	NFC: 0cm - 5cm
	Extended function(optional)	Bar Code Scanner, support SD5670/ N6603 QR code scanning
Communication	network	FDD-LTE/ TDD-LTE/ TDSCDMA 4G modem
	Bluetooth	BT4.1 BLE
	WIFI	IEEE 802.11 a/b/g/n 2.4G 5G
	USB	USB-Type C, supports fast charging and OTG
Electrical	Battery	6000mAh
	Battery life	-
	Battery charging	PE fast charging, full charge < 4 hours
Environment	Waterproof/Dustproof	IP67
	Shockproof	Withstand the impact of falling to cement floor at a height of 1.2m
	Humidity	5% - 95%
	Operating temperature	-20℃ ~ 60℃
	Storage temperature	-30℃ ~ 80℃
Physical	Dimension	160mm(L) × 80mm(W) × 15.8mm(H)
Physical	Weight	300g

Note: all information above is subject to change without any prior notice.
