INNO7

    5G, brings you an outstanding future

Model: INNO7

Download:

INNO7 Brochure

Features

未标题-2


Specification

GNSS Features Channels 336, 1598 (optional)
GPS L1C/A, L1C, L2C, L2E, L5
GLONASS L1C/A, L1P, L2C/A, L2P, L3
BDS B1, B2, B3
GALILEO E1, E5A, E5B, E5AltBOC, E6
SBAS L1C/A, L5 (Just for the satellites supporting L5)
IRNSS L5
QZSS L1C/A, L1 SAIF, L2C, L5, LEX
MSS L-Band Trimble RTX[1]
Positioning output rate 1Hz~50Hz
Initialization time < 10s
Initialization reliability >99.99%
Positioning Precision Code differential GNSS positioning Horizontal: 0.25 m + 1 ppm RMS
Vertical: 0.50 m + 1 ppm RMS
GNSS static Horizontal: 2.5 mm + 0.5 ppm RMS
Vertical: 5 mm + 0.5 ppm RMS
Long Observation Static Horizontal: 3mm+0.1 ppm
Vertical: 3.5mm+0.4ppm
Real-time kinematic
(Baseline<30km)		 Horizontal: 8 mm + 1 ppm RMS
Vertical: 15 mm + 1 ppm RMS
SLink (RTX)[2] Horizontal: 4-10 cm
Vertical: 8-20 cm
RTK XTRa (xFill)[3] Horizontal: 5 + 10 mm/min RMS
Vertical: 5 + 20 mm/min RMS
SBAS positioning Typically<5m 3DRMS
RTK initialization time 2~8s
IMU tilt 0°~60°
Hardware Performance Dimension 15.3cm(φ)×10.6cm(H)
Weight 1.2kg (battery included)
Material Magnesium aluminum alloy shell
Operating temperature –25 °C to +65 °C
Storage temperature –35 °C to +80 °C
Humidity 100% Non-condensing
Waterproof/Dustproof IP68 standard, protected from long time immersion to depth of 1m IP68 standard, fully protected against blowing dust
Shock/Vibration Withstand 2 meters pole drop onto the cement ground naturally
Power consumption 2W
Power supply 6-28V DC, overvoltage protection
Battery 7.4 V 3400mAh rechargeable, removable Lithium-ion battery
Battery life 16h (static mode)
10h (internal UHF base mode)
12h (rover mode)
Communications I/O Port 5PIN LEMO external power port + Rs232
7PIN LEMO +external USB(OTG)+Ethernet
1 UHF antenna interface
1 GPRS antenna interface (internal and external antenna switchable)
SIM card slot (standard)
Internal UHF Radio receive and transmit,
1W/2W/3W switchable, radio router and radio repeater
Frequency range 410-470MHz
Communication protocol Farlink, Trimtalk450s, SOUTH, SOUTH+,SOUTHx, HUACE, Hi-target, Satel
Communication range Typically 15km with Farlink protocol
Cellular mobile network Advanced 5G network communication module, downward compatible with 4G/3G
Bluetooth BLEBluetooth 4.0 standard, Bluetooth 2.1+EDR
NFC Communication Realizing close range (shorter than 10cm) automatic pair between receiver and controller(controller requires NFC wireless communication module else)
WIFI Modem 802.11 b/g standard
WIFI hotspot Receiver broadcasts its hotspot form web UI accessing with any mobile terminals
WIFI datalink Receiver can transmit and receive correction data stream via WiFi datalink
Data Storage/Transmission Storage 64GB SSD internal storage
Automatic cycle storage (The earliest data files will be removed automatically while the memory is not enough)
Support external USB storage
The customizable sample interval is up to 50Hz
Data transmission Plug and play mode of USB data transmission
Supports FTP/HTTP data download
Data format Differential data format: CMR, CMR+, SCMRx, RTCM 2.1,RTCM 2.3, RTCM 3.0, RTCM 3.1, RTCM 3.2
GPS output data format: NMEA 0183, PJK plane coordinate, Binary code, Trimble GSOF
Network model support: VRS, FKP, MAC, fully support NTRIP protocol
Sensors Electronic bubble Controller software can display electronic bubble, checking leveling status of the carbon pole in real-time
IMU Built-in IMU module, calibration-free and immue to magnetic interference
Thermometer Built-in thermometer sensor, adopting intelligent temperature control technology, monitoring and adjusting the receiver temperature
User Interaction Operating system Linux
Buttons 2-button and visual operation interface
Indicators 2 LED indicators, data interaction indicator and Bluetooth indicator
LCD 1.54-inch HD color LCD touch screen with resolution 240*240
Web interaction With the access of the internal web interface management via WiFi or USB connection, users are able to monitor the receiver status and change the configurations freely
Voice guidance The intelligent voice technology provides status and operation voice guidance, supports Chinese/English/Korean/Spanish/Portuguese/Russian/Turkish
Secondary development Provides secondary development package, and opens the OpenSIC observation data format and interaction interface definition
Cloud service The powerful cloud platform provides online services like remote manage, firmware update, online register and etc

[1] It requires a subscription to data service. [2] The RTX accuracies depend on correction service chosen. And 95% of the time with initializations are around 5-30 minutes. [3] RTK XTRa also requires a subscription to the data service, and precision is dependent on GNSS satellite availability. RTK XTRa positioning ends after 5 minutes of radio downtime.
