Specification

Aircraft System	aircraft type	VTOL (vertical takeoff and landing)
	wingspan	250 cm
	take-off weight	11 kg
	power supply	lithium polymer battery
	battery power	38500 mAh1 (fixed wing) 3700 mAh2 (rotor)
	body material	kevlar fiber material
Flight Performance	take-off method	vertical take-off
	landing method	vertical landing
	maximum ceiling	5500 m
	working height	--
	cruising speed*	typical 21 m/s (75 km/h)
	endurance	best up to 150 minutes
	single flight range*	maximum 180 km
	single flight coverage*	maximum 46 sq.km/GSD 10 cm
	landing space	vertical landing within 1 m
Operation Performance	base observations	autopilot
	radio datalink	--
	control frequency	1-2W
	radio communication range	3-20 km
	weather limit	beaufort scale 6 (10.8-13.8 m/s)
	operating temperature	-10℃ to 45℃
Ground Control	auto return	upon indications of low battery, airspeed anomaly, abnormal attitude
Ground Control	drone tracking	manually controlled, one-key operation

Note: all information above is subject to change without any prior notice.
