NS10

    • T-Drive, Smooth and Powerful Motorization • Reliable Prism Search: 300m • Auto Prism Recognition: 1000m • LocknTRack, never lost the target • Powerful EDM of 1000m in reflectorless mode • Quick and Easy Trigger Key • Guide Lights Red and Yellow LED • Camera for Assistance • Dustproof and Waterproof IP65

Model: NS10

Download:

NS10 New Brochure N80 PLUS Brochure

Features

T-Drive - Smooth and Powerful Motorization

The powerful robotic total station NS10 is a fully robotic solution which offers faster speed, improved motorization and higher precision in measurement.

No need for the traditional motion any more. Quick and reliable to turn to, lock, follow, measure and stake out the target.


Prisms Never Lose

1

Specification

Angle Measurement Measurement Method Absolute Encoding Disk
Diameter of Encoding Disk 79mm
Minimum Resolution 0.1″
Accuracy NS10 (0.5”): 0.5″
NS10 (1”): 1″
Telescope Image Erect
Magnification 30X
Tube Length 164.5mm
Effective Aperture 45mm (DTM: 47mm)
Field of View 1°30′
Minimum Focus 1.5m
Resolution 3″
Automatic Search*2 Target Aiming Range 1.5-300m
Measurement Time Typically: < 15 s
Angle Hz: 360°; V: 20°
Custom Search Support
Automatic Prism Following*2 Target Aiming Range 1.5-1000m
Measurement Time <5 s
Field of View 1.2°
Custom Search Support
General Compensator Dual-axis Liquid-electric sensor, Range: ±3’, Accuracy: 1”
T-P Sensor Automatic correction
Prism Constant Automatic correction
Display Unit Type: Colorful LCD Graphic Display, Touch Screen
Size: 6.0 Inches
Reading: Max.:99999999.9999m; min.:0.1mm
Operating System Android 9.0
Data Data Storage: RAM: 3GB; ROM: 32GB
Data Transfer: 4G/3G/2G, Bluetooth, WLAN, Hotspot, Micro USB, RS232
Power Management Voltage: 14.4V
Capacity: 6400mAh LI-ION battery
Working Time: 6 hours
Size 430mm*255mm*235mm
Weight 9.5 kg
Distance Measurement Range Triple prism: 6000m
Non-prism*1: 1000m
Accuracy: Prism Prism: ±(1+1*10-6.D)mm
Non-prism: 0-300m: (3+2*10-6.D)mm; 300-600m: (5+2*10-6.D)mm; >600m: (10+2*10-6.D)mm
Measurement Speed: Prism Prism: Repeat(<0.7s); Tracking(<0.3s); Single(<0.7s)
Non-prism: Single <600m, Typically 0.5-3s; Repeat >600m, max.10s; Tracking <500m, Typically 0.25-0.3s; >500m, max. 10s
Long-range Bluetooth Connection 500m

*1: White objects with high reflectivity (KGC 90%) *2: Standard Prism under good conditions (good visibility over 40km)
